Multi-Color LED Tower Light 1-5 Layers Adjustable Industrial Warning Lamp with Buzzer

Brand Name:	OUJVAN
MOQ:	2 pieces
Price:	$6/piece-$12/piece

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

Color Temperature(CCT):

RYGBW Customized

IP Rating:

IP54

Lamp Body Material:

ABS

Light Source:

LED

Beam Angle(°):

360

Color Rendering Index(Ra):

Emitting Color:

Red, Yellow, Green, Blue，White

Input Voltage(V):

DC 24 V /DC12V /AC110-AC240V Optional

Lamp Luminous Flux(lm):

400

Lifespan (Hours):

50000

Product Weight（kg）:

0.28

Support Dimmer:

Type:

Equipment Indicator Lights

Warranty(Year):

3-Year

Product Name:

Machine Tool Fault Alarm Multi-Layer Three-Color Signal Warning Light

Input Voltage:

DC 24 V /DC12V /AC110-AC240V Optional

Protection Grade:

IP54

Length Of The Wire:

0.5m

Buzzer:

>95dB

Shiny Number:

60-70/min

Glow Color:

Red,yellow,green

MOQ:

2 Pcs

Application:

CNC Machine

Functions:

Machine Tool Warning Light

Product Description

ABS 24V DC Multi Layer Machine Status Indicator Lights For CNC Machine Tools

Product Parameters

Parameter	Specification
Product Name	Equipment Indicator Lights
Model Number	Q1
Input Voltage	DC24V
Input Current	Monochromatic 30-70mA Buzzer: 15mA
Power	1.2W-2W
Protection Grade	IP53/IP65
Length of Wire	0.5m
Light Body Color	Black / White
Light Source	Patch 2835 LED
Light Life	50,000 hours
Surface Temperature	<50℃
Buzzer	>95dB
Flash Frequency	60-70/min
Material	Lampshade: PC Lamp Shell: ABS
Light Angle	360°
Glow Color	Red, Yellow, Green
Certification	CE, RoHS
Environment Temperature	-20~45℃
Storage Temperature	-40~70℃
Environmental Humidity	10~90%
Store Humidity	10~90%
MOQ	2 Pcs

Product Overview

The Q1 Series is a multilayer warning light designed for machine tools, featuring strong materials, precision machining, and efficient performance. It comes in black and white variants, with multiple mounting bases available to suit diverse industrial setups.

Technical Specifications

Current: 50mA per color, 25mA for the buzzer
Flash Frequency: 60-70 Hz/min
Buzzer Volume: >95dB
IP Rating: IP53 (with buzzer) or IP65 (without buzzer)
Temperature Resistance: <60°C
Lifespan: 50,000 hours
Installation: Fixed by screw
Material: ABS body, PC lens, and ABS base

Coding Principle

The Q1 Series offers extensive customization via its coding system:

Model No: Q1
Layer: Options include one-layer, two-layer, three-layer, and four-layer
Mounting: Collapsible (A) or threaded rod installation (E)
Voltage: DC12V (01), DC24V (02), or AC220V (03)
Function: Steady (B), Red flash (S), Steady with buzzer (F), or Red flash with buzzer (C)
Connect Type: PNP&NPN (T) or Contact type (C)
Color: Red (R), Yellow (Y), Green (G)
Diameter: 50mm (φ50) or 60mm (φ60)
Light Body: White (W) or Black (B)

Features & Design

Light Source & Power: Utilizes a constant current drive power supply and imported LED color light sources for luminous equilibrium. Supports segmental independent installation.
Base Design: The base can rotate 180 degrees and fold 90 degrees, enabling easy installation and adaptability to complex scenarios.
Durability & Performance: Boasts wafer encapsulation, high and low temperature resistance, and a loud, clear buzzer for effective warnings.

Applications

Ideal for machine tools, automated production lines, and other industrial equipment requiring clear operational status signaling. With its patent-backed design, customizable branding, RYGBW 1-5 layers customized, DC 24V/DC12V/AC110-AC240V optional and adaptability to multiple industrial scenarios, this LED lamp series elevates equipment visibility, identification, and operational safety—making it a versatile choice for both indication and brand personalization in automation and manufacturing environments.

Product Images

Frequently Asked Questions

How to order our product?

1. Please tell us the model and quantity and other request you need.
2. We make the PI for you.
3. After you confirm the PI, we arrange the order for you after receiving your payment.
4. After the goods finished, we send the goods out to you and tell you the tracking number.
5. We will track your goods until you receive the goods.

What's your warranty?

One year

What's your shipment method?

We ship by Express, by air, by sea, by train. Normally we checked and compare, then provide customer the most proper shipment method.

What's about MOQ?

First order MOQ = 1 piece

If I want to release order, what's the payment method you accept?

We accept T/T, Paypal, Western union, L/C.

If I want to release order, what's the process?

Thanks. You can send inquiry to us by email, we will reply within 24hrs. Thank you & Now pls send your kindly inquiry!
